AM2520SURCK09
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Z-Bend, Bottom Entry
Category Optoelectronics / LED Indication - Discrete
Description
LED 2.5X2 630NM RED WTR CLR SMD
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.30008
≥100 USD $0.198704
Inventory: 1462
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount, Bottom Entry
Package / Case 2-SMD, Z-Bend, Bottom Entry
Technical
Packaging Tape & Reel (TR)
Published 2012
Size / Dimension 2.50mm Lx2.00mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature HIGH RELIABILITY
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 5.05mm
Configuration Standard
Voltage - Forward (Vf) (Typ) 1.95V
Viewing Angle 20°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Round with Domed Top
Lens Size 1.90mm Dia
Luminous Intensity 2.4 cd
Millicandela Rating 1000mcd
Lens Transparency Clear
Wavelength - Peak 645nm
Lens Color Colorless
Forward Voltage-Max 2.5V
Wavelength - Dominant 630nm
T-code T-3/4
Reverse Voltage-Max 5V
Dimensions
Height 2.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
