AM2520SURCK03
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Gull Wing
Category Optoelectronics / LED Indication - Discrete
Description
LED RED CLEAR SMD
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.32384
≥100 USD $0.186032
Inventory: 19308
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 2.8mm
Technical
Reverse Voltage-Max 5V
T-code T-3/4
Wavelength - Dominant 630nm
Forward Voltage-Max 2.5V
Lens Color Colorless
Wavelength - Peak 645nm
Lens Transparency Clear
Millicandela Rating 1000mcd
Luminous Intensity 1.8 cd
Lens Size 1.90mm Dia
Lens Style Round with Domed Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 20°
Voltage - Forward (Vf) (Typ) 1.95V
Configuration Standard
Terminal Pitch 4.6mm
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 2.50mm Lx2.00mm W
Published 2005
Packaging Tape & Reel (TR)
Physical
Package / Case 2-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
