AM2520MGC09
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Z-Bend
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD Green 570nm Water Clear 600mcd
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7744
≥1 USD $0.7744
≥10 USD $0.50248
≥100 USD $0.329296
Inventory: 1475
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 2.9mm
Technical
Reverse Voltage-Max 5V
T-code T-3/4
Wavelength - Dominant 570nm
Forward Voltage-Max 2.5V
Lens Color Colorless
Wavelength - Peak 574nm
Lens Transparency Clear
Millicandela Rating 1000mcd
Luminous Intensity 1 cd
Lens Size 1.90mm Dia
Lens Style Round with Domed Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 20°
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Terminal Pitch 5.05mm
Number of Functions 1
Packing Method TAPE AND REEL
Power Rating 75mW
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 2.50mm Lx2.00mm W
Published 2011
Packaging Tape & Reel (TR)
Physical
Package / Case 2-SMD, Z-Bend
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
