AA2810ASES/J3

Kingbright
RoHS
RoHS RoHS compliant
Package 2-SMD, J-Lead
Category Optoelectronics / LED Indication - Discrete
Description LED RED CLEAR CHIP SMD R/A
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.748
≥1 USD $0.748
≥10 USD $0.48752
≥100 USD $0.319176
≥500 USD $0.251979
Inventory: 49652
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Package / Case 2-SMD, J-Lead
Shape RECTANGULAR

Technical

Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 2.50mm Lx1.20mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
HTS Code 8541.40.20.00
Power Rating 84mW
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 2.4mm
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 110°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 2.30mmx0.57mm
Luminous Intensity 550 mcd
Millicandela Rating 550mcd
Lens Transparency Clear
Wavelength - Peak 640nm
Lens Color Colorless
Wavelength - Dominant 625nm
T-code T-1

Dimensions

Height 800μm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
