IN-S42ATB
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED BLUE CLEAR 0402 SMD
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.24816
≥100 USD $0.165616
≥500 USD $0.114541
≥1000 USD $0.095454
≥3000 USD $0.085914
Inventory: 16490
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0402 (1005 Metric)
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Cut Tape (CT)
Published 2017
Series IN-S42AT
Size / Dimension 1.00mm Lx0.50mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Color Blue
Additional Feature HIGH RELIABILITY
Packing Method TR, 7 INCH
Number of Functions 1
Terminal Pitch 1mm
Operating Temperature (Max) 80°C
Operating Temperature (Min) -30°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.1V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 0.60mmx0.45mm
Luminous Intensity 100.0 mcd
Millicandela Rating 100mcd
Wavelength - Peak 468nm
Lens Color Clear
Forward Current-Max 0.025A
Forward Voltage-Max 4V
Overall Height 0.45mm
Wavelength - Dominant 470nm
Number of LEDs 1
Reverse Voltage-Max 5V
Dimensions
Height (Max) 0.55mm
Compliance
RoHS Status ROHS3 Compliant
