QTLP9123GR image
Favorite
QTLP9123GR image
Favorite
RoHS
RoHS RoHS compliant
Package 2-SMD, Gull Wing
Category Optoelectronics / LED Indication - Discrete
Description Round with Domed Top 1 Yellow Standard LED Indication Discrete 5V 20mA 30mcd 25°
PDF
/
Inventory: 2331
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 3mm

Technical

Reverse Voltage-Max 5V
Number of LEDs 1
Wavelength - Peak 585nm
Lens Transparency Clear
Millicandela Rating 30mcd
Luminous Intensity 30 mcd
Lens Size 1.90mm Dia
Lens Style Round with Domed Top
Forward Current 20mA
Viewing Angle 25°
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Subcategory Visible LEDs
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 2.50mm Lx2.00mm W
Published 1999
Packaging Tape & Reel (TR)

Physical

Number of Pins 2
Package / Case 2-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount, Through Hole

Supply Chain

Factory Lead Time 12 Weeks
