QTLP651CRAGTR
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD Red/Green LED Bi Color
PDF
/
Inventory: 6795
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 1.50mm
Width 1.5mm
Length 3mm
Height 1.5mm
Technical
Wavelength - Peak 630nm Red 575nm Yellow-Green
Illumination Color Green, Red
Millicandela Rating 50mcd Red, 25mcd Yellow-Green
Luminous Intensity 25 mcd
Forward Voltage 2V
Current - Test 20mA Red 20mA Yellow-Green
Forward Current 20mA
Viewing Angle 60°
Voltage - Forward (Vf) (Typ) 2V Red 2V Yellow-Green
Case Code (Imperial) 1206
Case Code (Metric) 3216
Color Red, Yellow-Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 3.00mm Lx1.50mm W
Published 2001
Packaging Tape & Reel (TR)
Physical
Supplier Device Package 1206
Number of Pins 1206
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
