MV5491A
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
Round with Domed Top 1 DUAL COLOR LED Green Red LED Indication Discrete 5V 20mA Green 20mA Red 5mcd Green 5mcd Red 120mW
PDF
/
Inventory: 2437
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Technical
Packaging Bulk
Published 2000
Size / Dimension 5.00mm Dia
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Green, Red
Additional Feature HIGH RELIABILITY
Number of Functions 1
Depth 5.84mm
Configuration Bidirectional
Power Dissipation 120mW
Voltage - Forward (Vf) (Typ) 2V Green 2V Red
Viewing Angle 75°
Optoelectronic Device Type DUAL COLOR LED
Forward Current 30mA
Current - Test 20mA Green 20mA Red
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 5 mcd
Millicandela Rating 5mcd Green, 5mcd Red
Illumination Color Green, Red
Lens Transparency Diffused
Wavelength - Peak 565nm Green 660nm Red
Lens Color White
Reverse Voltage 5V
Number of LEDs 2
Dimensions
Height 12.19mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
