MV5437RA
RoHS
RoHS compliant
RoHS compliantPackage Radial - 3 Leads
Category Optoelectronics / LED Indication - Discrete
Description
Round with Domed Top 1 DUAL COLOR LED Green Red LED Indication Discrete 3V 20mA Green 20mA Red 6mcd Green 6mcd Red 100°
PDF
/
Inventory: 8519
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial - 3 Leads
Number of Pins 3
Shape RECTANGULAR
Technical
Packaging Bulk
Published 2001
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Color Green, Red
Subcategory Visible LEDs
Number of Functions 1
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration Bidirectional
Voltage - Forward (Vf) (Typ) 2.1V Green 2.1V Red
Viewing Angle 100°
Optoelectronic Device Type DUAL COLOR LED
Forward Current 30mA
Current - Test 20mA Green 20mA Red
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 6 mcd
Millicandela Rating 6mcd Green, 6mcd Red
Illumination Color Green, Red
Lens Transparency Diffused
Wavelength - Peak 565nm Green 635nm Red
Lens Color White
Forward Voltage-Max 3V
Number of LEDs 2
Dimensions
Height 10.08mm
Compliance
RoHS Status ROHS3 Compliant
