HLMP6405AZR
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Z-Bend
Category Optoelectronics / LED Indication - Discrete
Description
Round with Domed Top 1 Yellow Standard LED Indication Discrete 3V 10mA 12mcd 25°
PDF
/
Inventory: 6803
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 2.92mm
Technical
Reverse Voltage-Max 5V
Number of LEDs 1
Forward Voltage-Max 3V
Lens Color Colorless
Wavelength - Peak 585nm
Lens Transparency Clear
Millicandela Rating 12mcd
Luminous Intensity 12 mcd
Lens Size 1.90mm Dia
Lens Style Round with Domed Top
Forward Current 10mA
Viewing Angle 25°
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Subcategory Visible LEDs
Color Yellow
Min Operating Temperature -55°C
Max Operating Temperature 100°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 2.20mm Lx2.10mm W
Published 2003
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case 2-SMD, Z-Bend
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
