7343-2SURC/H2/S400-A8
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Red 632nm 2-Pin T-1 3/4 T/R
PDF
/
Inventory: 3963
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 5.9mm
Height 8.85mm
Technical
Wavelength - Dominant 624nm
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 632nm
Lens Transparency Clear
Millicandela Rating 2000mcd
Luminous Intensity 2 cd
Lens Size 5mm T-1 3/4
Lens Style Round with Domed Top
Current - Test 20mA
Forward Current 50mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 30°
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 120mW
Configuration Standard
Number of Elements 1
Depth 5.9mm
Number of Functions 1
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2005
Packaging Bulk
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
