67-21/R6C-AP2R1B/2A0
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Z-Bend
Category Optoelectronics / LED Indication - Discrete
Description
LED RED CLEAR 2PLCC SMD
PDF
/
Inventory: 5147
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 2mm
Technical
Number of LEDs 1
Wavelength - Dominant 626nm
Lens Color Colorless
Wavelength - Peak 632nm
Lens Transparency Clear
Luminous Intensity 99 mcd
Lens Size 2.40mm Dia
Lens Style Round with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.05V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 4.5mm
Number of Functions 1
Packing Method TAPE AND REEL
Color Red
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.50mm Lx2.70mm W
Published 2008
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case 2-SMD, Z-Bend
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
