57-21/R6C-AP1Q2B/BF
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Boomerang
Category Optoelectronics / LED Indication - Discrete
Description
LED RED CLEAR SMD R/A
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.149496
≥1 USD $0.149496
≥10 USD $0.122286
≥100 USD $0.110617
Inventory: 484
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 4mm
Technical
Number of LEDs 1
Wavelength - Dominant 626nm
Lens Color Colorless
Wavelength - Peak 632nm
Lens Transparency Clear
Luminous Intensity 79 mcd
Lens Size 2.20mm Dia
Lens Style Round with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.05V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Packing Method TAPE AND REEL 7"
Color Red
Number of Terminations 2
Moisture Sensitivity Level (MSL) 5 (48 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 4.00mm Lx3.60mm W
Published 2009
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case 2-SMD, Boomerang
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
