48-21/T1D-ANPHY/3C

Everlight Electronics Co Ltd
RoHS
RoHS RoHS compliant
Package 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description LED WHITE DIFFUSED CHIP SMD R/A
PDF
/
Inventory: 3812
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 550μm

Technical

Number of LEDs 1
Lens Color Yellow
Lens Transparency Diffused
Luminous Intensity 50 mcd
Lens Size 1.20mmx0.50mm
Lens Style Rectangle with Flat Top
Current - Test 5mA
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 2.92V
Current 2A
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Packing Method TAPE AND REEL 7"
Color White
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Size / Dimension 1.80mm Lx1.10mm W
Published 2005
Packaging Tape & Reel (TR)

Physical

Shape RECTANGULAR
Number of Pins 2
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
