339-1SURSYGW/S530-A4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LED Indication - Discrete
Description
LED
PDF
/
Inventory: 5134
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount NO
Mounting Feature RADIAL MOUNT
Shape ROUND
Technical
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 3
Color HYPER RED/SUPER YELLOW GREEN
Additional Feature IC COMPATIBLE, HIGH RELIABILITY
HTS Code 8541.40.20.00
Packing Method BOX/CARTON
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code compliant
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration COMMON CATHODE, 2 ELEMENTS
Viewing Angle 70 deg
Optoelectronic Device Type DUAL COLOR LED
Size 5mm
Luminous Intensity 125.0/80.0 mcd
Lens Type DIFFUSED WHITE
Forward Current-Max 0.025A
Overall Height 8.6mm
T-code T-1 3/4
Peak Wavelength 632/575 nm
Compliance
RoHS Status RoHS Compliant
