22-23A/R6GTB3C-D01/2C
RoHS
/
Package 4-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED RGB CLEAR CHIP SMD R/A
PDF
/
Inventory: 1164
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height 800μm
Technical
Number of LEDs 3
Wavelength - Dominant 624nm Red 530nm Green 470nm Blue
Forward Current-Max 0.025A
Lens Color Colorless
Wavelength - Peak 632nm Red 518nm Green 468nm Blue
Lens Transparency Clear
Millicandela Rating 12.6mcd Red, 40mcd Green, 8mcd Blue
Luminous Intensity 8 mcd
Lens Size 1.50mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 2mA Red 2mA Green 2mA Blue
Optoelectronic Device Type TRIPLE COLOR LED
Viewing Angle 130°
Voltage - Forward (Vf) (Typ) 1.8V Red 2.85V Green 2.8V Blue
Configuration Common Anode
Operating Temperature (Max) 85°C
Number of Functions 1
Packing Method TAPE AND REEL 7"
Additional Feature SUPPORTS INFRARED
Color Red, Green, Blue (RGB)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 2.70mm Lx1.35mm W
Published 2008
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 4
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
