17-21/GHC-YR1S2/3T
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR 0805 SMD
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0285
≥1 USD $0.0285
≥10 USD $0.0228
≥100 USD $0.0228
≥500 USD $0.02185
≥1000 USD $0.0209
≥9000 USD $0.019
Inventory: 148835
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 1mm
Technical
Number of LEDs 1
Wavelength - Dominant 528nm
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 518nm
Lens Transparency Clear
Luminous Intensity 199 mcd
Lens Size 1.40mmx1.25mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 3.3V
Configuration Standard
Number of Functions 1
Max Power Dissipation 110mW
Packing Method TAPE AND REEL 7"
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 2.00mm Lx1.25mm W
Published 2005
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
