12-23A/R6GHBHC-A01/2D

Everlight Electronics Co Ltd
RoHS
RoHS RoHS compliant
Package 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description Standard LEDs - SMD RGB WATER CLEAR RIGHT ANGLE LENS
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.08075
≥1 USD $0.08075
≥10 USD $0.0665
≥100 USD $0.0646
≥500 USD $0.0627
≥1000 USD $0.05985
Inventory: 672
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 2.1mm

Technical

Number of LEDs 3
Wavelength - Dominant 624nm Red 525nm Green 470nm Blue
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 632nm Red 518nm Green 468nm Blue
Lens Transparency Clear
Millicandela Rating 90mcd Red, 180mcd Green, 72mcd Blue
Luminous Intensity 72 mcd
Lens Size 2.00mmx1.00mm
Lens Style Rectangle with Domed Top
Current - Test 20mA Red 20mA Green 20mA Blue
Forward Current 20mA
Optoelectronic Device Type TRIPLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2V Red 3.3V Green 3.3V Blue
Configuration Common Anode
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 110mW
Color Red, Green, Blue (RGB)
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.00mm Lx2.00mm W
Published 2009
Packaging Tape & Reel (TR)

Physical

Shape RECTANGULAR
Number of Pins 4
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
