5988920307F
RoHS
RoHS compliant
RoHS compliantPackage 1210 (3225 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED RGB CLEAR 1210 SMD
PDF
/
Inventory: 4884
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 1.00mm
Technical
Wavelength - Dominant 625nm Red-Orange 525nm Green 470nm Blue
Forward Current-Max 0.02A
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 120mcd Red-Orange, 150mcd Green, 60mcd Blue
Luminous Intensity 120.0/150.0/60.0 mcd
Lens Size 2.00mmx1.30mm
Lens Style Rectangle with Flat Top
Current - Test 20mA Red-Orange 20mA Green 20mA Blue
Optoelectronic Device Type TRIPLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 2V Red-Orange 3.2V Green 3.2V Blue
Configuration Common Anode
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Reach Compliance Code compliant
Terminal Pitch 3.2mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
HTS Code 8541.40.20.00
Color Red, Green, Blue (RGB)
Terminal Finish Nickel/Gold (Ni/Au)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 3.20mm Lx2.70mm W
Series 598
Published 2013
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 1210 (3225 Metric)
Mounting Type Surface Mount
