5988520207F
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED CLEAR 1208 SMD R/A
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.4664
≥1 USD $0.4664
≥10 USD $0.28776
≥100 USD $0.165616
≥500 USD $0.129589
Inventory: 1525
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 1.00mm
Technical
Reverse Voltage-Max 5V
Wavelength - Dominant 568nm Green 625nm Red
Overall Height 1.48mm
Forward Voltage-Max 2.4V
Forward Current-Max 0.02A
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 40mcd Green, 110mcd Red
Luminous Intensity 110.0/40.0 mcd
Lens Size 2.00mmx1.00mm
Lens Style Rectangle with Domed Top
Current - Test 20mA Green 20mA Red
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 160°
Voltage - Forward (Vf) (Typ) 2V Green 2V Red
Configuration Independent
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Number of Functions 1
Packing Method TAPE AND REEL 7"
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Color Green, Red
Terminal Finish Nickel/Gold (Ni/Au)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 3.20mm Lx1.50mm W
Series 598
Published 2002
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
