5988520202F
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED CLEAR 1208 SMD R/A
PDF
/
Inventory: 6912
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount, Right Angle
Package / Case 2-SMD, No Lead
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Strip
Published 2013
Series 598
Size / Dimension 3.20mm Lx1.50mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 4
Terminal Finish Nickel/Gold (Ni/Au)
Color Green, Red
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method TAPE
Number of Functions 1
Operating Temperature (Max) 100°C
Operating Temperature (Min) -40°C
Configuration SEPARATE, 2 ELEMENTS
Voltage - Forward (Vf) (Typ) 2V Green 2V Red
Viewing Angle 160°
Optoelectronic Device Type DUAL COLOR LED
Current - Test 20mA Green 20mA Red
Lens Style Rectangle with Domed Top
Lens Size 2.00mmx1.00mm
Luminous Intensity 110.0/40.0 mcd
Millicandela Rating 40mcd Green, 110mcd Red
Lens Transparency Clear
Lens Color Colorless
Forward Current-Max 0.02A
Forward Voltage-Max 2.4V
Overall Height 1.48mm
Wavelength - Dominant 568nm Green 625nm Red
Reverse Voltage-Max 5V
Dimensions
Height (Max) 1.00mm
Compliance
RoHS Status ROHS3 Compliant
