5988230102F
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE CLEAR 1206 SMD
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.008307
≥1 USD $1.008307
≥200 USD $0.40306
≥500 USD $0.389931
≥1000 USD $0.382054
Inventory: 5877
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.70mm
Technical
Reverse Voltage-Max 5V
Wavelength - Dominant 605nm
Overall Height 0.68mm
Forward Voltage-Max 2.4V
Forward Current-Max 0.025A
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 110mcd
Luminous Intensity 110.0 mcd
Lens Size 2.00mmx1.60mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Operating Temperature (Min) -30°C
Operating Temperature (Max) 85°C
Terminal Pitch 3.5mm
Number of Functions 1
Packing Method TAPE
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Color Orange
Terminal Finish Nickel/Gold (Ni/Au)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 3.20mm Lx1.60mm W
Series 598
Published 2013
Packaging Strip
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
