5988110107F
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
DIALIGHT - 5988110107F - LED, Red, SMD, 0805, 20 mA, 2.2 V, 642 nm
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
≥10 USD $0.2024
≥100 USD $0.090904
≥500 USD $0.082122
≥1000 USD $0.067461
≥3000 USD $0.058661
Inventory: 164802
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2007
Series 598
Size / Dimension 2.00mm Lx1.25mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Terminal Finish Nickel/Gold (Ni/Au)
Color Red
HTS Code 8541.40.20.00
Packing Method TR, 7 INCH
Number of Functions 1
Terminal Pitch 2.25mm
Operating Temperature (Max) 85°C
Operating Temperature (Min) -30°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 140°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.40mmx1.25mm
Luminous Intensity 40.0 mcd
Millicandela Rating 40mcd
Lens Transparency Clear
Lens Color Colorless
Forward Current-Max 0.025A
Overall Height 0.7mm
Wavelength - Dominant 635nm
Dimensions
Height (Max) 0.80mm
Compliance
RoHS Status ROHS3 Compliant
