5977701507F
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED CLEAR 4SMD
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
≥10 USD $0.51832
≥100 USD $0.339416
≥500 USD $0.267978
Inventory: 1147
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 1.30mm
Technical
Wavelength - Dominant 575nm Green 653nm Red
Overall Height 1.3mm
Forward Current-Max 0.025A
Lens Color Colorless
Wavelength - Peak 570nm Green 650nm Red
Lens Transparency Clear
Millicandela Rating 16mcd Green, 6.3mcd Red
Luminous Intensity 6.3/16.0 mcd
Lens Size 2.30mmx2.10mm
Lens Style Rectangle with Flat Top
Current - Test 20mA Green 20mA Red
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 100°
Voltage - Forward (Vf) (Typ) 2.2V Green 2V Red
Configuration Independent
Operating Temperature (Min) -30°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.7mm
Number of Functions 1
Packing Method TAPE AND REEL
HTS Code 8541.40.20.00
Color Green, Red
Terminal Finish Nickel/Gold (Ni/Au)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 3.00mm Lx2.50mm W
Series 597
Published 2002
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 4 Weeks
