5976601602F
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED BLUE CLEAR 1206 SMD
PDF
/
Buying Options
Total Price: USD $1.5
Unit Price: USD $1.5048
≥1 USD $1.5048
≥10 USD $0.95084
≥100 USD $0.703736
≥500 USD $0.646694
≥1000 USD $0.532567
≥3000 USD $0.505938
Inventory: 129
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount, Bottom Entry
Package / Case 1206 (3216 Metric)
Technical
Packaging Strip
Published 2008
Series 597
Size / Dimension 3.20mm Lx1.60mm W
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Color Blue
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Operating Temperature (Max) 85°C
Operating Temperature (Min) -55°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 3V
Viewing Angle 70°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Flat Top
Lens Size 1.60mm Dia
Millicandela Rating 112.5mcd
Lens Transparency Clear
Wavelength - Peak 468nm
Lens Color Colorless
Forward Current-Max 0.02A
Forward Voltage-Max 3.8V
Overall Height 1.1mm
Wavelength - Dominant 470nm
Reverse Voltage-Max 5V
Dimensions
Height (Max) 1.10mm
Compliance
RoHS Status ROHS3 Compliant
