5975311407
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN 2SMD
PDF
/
Inventory: 1866
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.79mm
Technical
Overall Height 0.787mm
Forward Voltage-Max 2.8V
Forward Current-Max 0.025A
Wavelength - Peak 560nm
Millicandela Rating 6.4mcd
Luminous Intensity 6.4 mcd
Lens Size 1.20mmx1.25mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Operating Temperature (Min) -30°C
Operating Temperature (Max) 85°C
Reach Compliance Code compliant
Terminal Pitch 2.25mm
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature SUPPORTS INFRARED
Color Green
Terminal Finish Copper/Nickel/Gold (Cu/Ni/Au)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 2.00mm Lx1.25mm W
Series microLED?
Published 2002
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
