5975311402F
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN DIFFUSED 2SMD
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.590805
≥1 USD $0.590805
≥200 USD $0.236322
≥500 USD $0.228445
≥1000 USD $0.224506
Inventory: 1507
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.79mm
Technical
Wavelength - Dominant 567nm
Overall Height 0.787mm
Forward Voltage-Max 2.8V
Forward Current-Max 0.025A
Lens Color White
Wavelength - Peak 560nm
Lens Transparency Diffused
Millicandela Rating 6.4mcd
Luminous Intensity 6.4 mcd
Lens Size 1.19mmx1.24mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 150°
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Operating Temperature (Min) -30°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.25mm
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature SUPPORTS INFRARED
Color Green
Terminal Finish Copper/Nickel/Gold (Cu/Ni/Au)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 2.00mm Lx1.25mm W
Series 597
Published 2002
Packaging Strip
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
