5975213402F
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE DIFFUSED 0603 SMD
PDF
/
Buying Options
Total Price: USD $1.92
Unit Price: USD $1.9184
≥1 USD $1.9184
≥10 USD $1.27952
Inventory: 104
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.70mm
Technical
Wavelength - Dominant 605nm
Overall Height 0.7mm
Forward Voltage-Max 2.4V
Forward Current-Max 0.03A
Lens Color White
Wavelength - Peak 609nm
Lens Transparency Diffused
Millicandela Rating 65mcd
Luminous Intensity 65.0 mcd
Lens Size 1.10mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 152°
Voltage - Forward (Vf) (Typ) 1.9V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 1.6mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature SUPPORTS INFRARED
Color Orange
Terminal Finish Copper/Nickel/Gold (Cu/Ni/Au)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 1.60mm Lx0.80mm W
Series 597
Published 2008
Packaging Strip
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
