5975112407F
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED RED DIFFUSED 0603 SMD
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.524261
≥1 USD $0.524261
≥10 USD $0.494591
≥100 USD $0.46659
≥500 USD $0.440182
≥1000 USD $0.415264
Inventory: 1290
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2008
Series 597
Size / Dimension 1.60mm Lx0.80mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Terminal Finish Copper/Nickel/Gold (Cu/Ni/Au)
Color Red
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 1.6mm
Operating Temperature (Max) 85°C
Operating Temperature (Min) -30°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 1.7V
Viewing Angle 152°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.10mmx0.80mm
Luminous Intensity 11.7 mcd
Millicandela Rating 11.7mcd
Lens Transparency Diffused
Wavelength - Peak 660nm
Lens Color White
Forward Current-Max 0.025A
Forward Voltage-Max 2.3V
Overall Height 0.7mm
Wavelength - Dominant 647nm
Dimensions
Height (Max) 0.70mm
Compliance
RoHS Status ROHS3 Compliant
