5973327507F
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1006 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR 0402 SMD
PDF
/
Buying Options
Total Price: USD $1.18
Unit Price: USD $1.1792
≥1 USD $1.1792
≥10 USD $0.74624
≥100 USD $0.552464
≥500 USD $0.50769
≥1000 USD $0.418088
≥3000 USD $0.397188
Inventory: 1087
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0402 (1006 Metric)
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Cut Tape (CT)
Published 2013
Size / Dimension 1.00mm Lx0.60mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Color Green
HTS Code 8541.40.20.00
Packing Method TR, 7 INCH
Number of Functions 1
Terminal Pitch 0.9mm
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 135°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Square with Flat Top
Lens Size 0.60mm
Luminous Intensity 110.0 mcd
Millicandela Rating 13mcd
Lens Transparency Clear
Lens Color Colorless
Forward Current-Max 0.005A
Overall Height 0.2mm
Wavelength - Dominant 560nm
Dimensions
Height (Max) 0.25mm
Compliance
RoHS Status ROHS3 Compliant
