5973301107F

Dialight
RoHS
RoHS RoHS compliant
Package 4-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description LED GREEN CLEAR 1210 SMD
PDF
/
Inventory: 3243
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mounting Type Surface Mount
Package / Case 4-SMD, No Lead
Surface Mount YES

Technical

Packaging Tape & Reel (TR)
Published 2002
Series 597
Size / Dimension 2.54mm Lx3.00mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
Terminal Finish Silver/Platinum (Ag/Pt)
Color Green
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 2.75mm
Reach Compliance Code compliant
Operating Temperature (Max) 75°C
Operating Temperature (Min) -30°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 2V
Viewing Angle 170°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Square with Flat Top
Lens Size 1.70mm
Luminous Intensity 12.0 mcd
Millicandela Rating 12mcd
Lens Transparency Clear
Lens Color Colorless
Forward Current-Max 0.025A
Forward Voltage-Max 2.6V
Overall Height 1.21mm
Wavelength - Dominant 565nm
Peak Wavelength 565 nm

Dimensions

Height (Max) 1.21mm

Compliance

RoHS Status RoHS Compliant
