5973006607F
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED RED CLEAR 0805 SMD
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
≥10 USD $0.45848
≥100 USD $0.300608
≥500 USD $0.23731
Inventory: 1331
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Wavelength - Dominant 630nm
Forward Current-Max 0.03A
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 6mcd
Lens Size 1.19mmx1.24mm
Lens Style Rectangle with Flat Top
Current - Test 10mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 130°
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Operating Temperature (Min) -55°C
Operating Temperature (Max) 85°C
Number of Functions 1
Packing Method TR, 7 INCH
HTS Code 8541.40.20.00
Color Red
Terminal Finish Nickel/Gold (Ni/Au)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e4
Size / Dimension 2.00mm Lx1.25mm W
Series 597
Published 2013
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
