5972712602F
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED RGB DIFFUSED 1208 SMD R/A
PDF
/
Buying Options
Total Price: USD $3.47
Unit Price: USD $3.4672
≥1 USD $3.4672
≥10 USD $2.45432
≥100 USD $2.010272
≥500 USD $1.694722
≥1000 USD $1.554467
≥3000 USD $1.490183
Inventory: 2102
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount, Right Angle
Package / Case 4-SMD, No Lead
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Strip
Published 2011
Series 597
Size / Dimension 3.00mm Lx1.50mm W
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 4
Terminal Finish Gold (Au)
Color Red, Green, Blue (RGB)
HTS Code 8541.40.20.00
Packing Method TAPE AND REEL 7"
Number of Functions 1
Operating Temperature (Max) 80°C
Operating Temperature (Min) -20°C
Configuration Common Anode
Voltage - Forward (Vf) (Typ) 2V Red 3.5V Green 3.5V Blue
Viewing Angle 130°
Optoelectronic Device Type TRIPLE COLOR LED
Current - Test 20mA Red 20mA Green 20mA Blue
Lens Style Rectangle with Domed Top
Lens Size 2.00mmx1.00mm
Luminous Intensity 112.5/281.0/104.0 mcd
Millicandela Rating 112.5mcd Red, 281mcd Green, 104mcd Blue
Lens Transparency Diffused
Wavelength - Peak 632nm Red 520nm Green 468nm Blue
Lens Color White
Forward Current-Max 0.03A
Overall Height 1mm
Wavelength - Dominant 624nm Red 525nm Green 470nm Blue
Dimensions
Height (Max) 1.00mm
Compliance
RoHS Status ROHS3 Compliant
