5972003502F

Dialight
RoHS
RoHS RoHS compliant
Package 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description LED RED CLEAR 0605 SMD R/A
PDF
/
Inventory: 5265
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mounting Type Surface Mount, Right Angle
Package / Case 2-SMD, No Lead
Surface Mount YES
Shape RECTANGULAR

Technical

Packaging Strip
Published 2010
Series 597
Size / Dimension 1.60mm Lx1.15mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Color Red
HTS Code 8541.40.20.00
Number of Functions 1
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 135°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.20mmx0.55mm
Luminous Intensity 40.0 mcd
Millicandela Rating 40mcd
Lens Transparency Clear
Lens Color Colorless
Forward Current-Max 0.02A
Overall Height 0.55mm
Wavelength - Dominant 630nm

Dimensions

Height (Max) 0.55mm

Compliance

RoHS Status ROHS3 Compliant
