5219651F
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED DIFFUSED 5MM T/H
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.584
≥1 USD $1.584
≥10 USD $1.05688
≥100 USD $0.813296
≥500 USD $0.735222
≥1000 USD $0.631822
≥3000 USD $0.597362
Inventory: 862
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Technical
Packaging Bulk
Series 521
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Color Green, Red
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Number of Functions 1
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration COMMON BIPOLAR TERMINAL, 2 ELEMENTS
Voltage - Forward (Vf) (Typ) 2.1V Green 1.8V Red
Viewing Angle 60°
Optoelectronic Device Type DUAL COLOR LED
Current - Test 20mA Green 20mA Red
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Luminous Intensity 90.0/40.0 mcd
Millicandela Rating 40mcd Green, 90mcd Red
Lens Transparency Diffused
Wavelength - Peak 565nm Green 660nm Red
Lens Color White
Forward Current-Max 0.04A
Forward Voltage-Max 2.4V
Overall Height 8.64mm
T-code T-1 3/4
Dimensions
Height (Max) 8.64mm
Compliance
RoHS Status ROHS3 Compliant
