5219636F
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED RED DIFFUSED 3MM T/H
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.0648
≥1 USD $1.0648
≥10 USD $0.67584
≥100 USD $0.49984
≥500 USD $0.378277
≥1000 USD $0.351252
≥3000 USD $0.343147
Inventory: 393
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Technical
Packaging Bulk
Published 2008
Series 521
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Color Red
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Number of Functions 1
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.4V
Viewing Angle 60°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 3.00mm Dia
Luminous Intensity 60.0 mcd
Millicandela Rating 60mcd
Lens Transparency Diffused
Wavelength - Peak 660nm
Forward Current-Max 0.04A
Forward Voltage-Max 2.4V
Overall Height 4.4mm
Wavelength - Dominant 638nm
T-code T-1
Reverse Voltage-Max 4V
Luminous Intensity-Min 60 cd
Dimensions
Height (Max) 5.86mm
Compliance
RoHS Status ROHS3 Compliant
