5219459
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED DIFFUSED 3MM T/H
PDF
/
Inventory: 3565
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Technical
Packaging Bulk
Published 2002
Series 521
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Color Green, Red
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Number of Functions 1
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration Bidirectional
Voltage - Forward (Vf) (Typ) 2.1V Green 2V Red
Viewing Angle 50°
Optoelectronic Device Type DUAL COLOR LED
Current - Test 10mA Green 10mA Red
Lens Style Round with Domed Top
Lens Size 3.00mm Dia
Luminous Intensity 4.7/10.0 mcd
Millicandela Rating 10mcd Green, 4.7mcd Red
Lens Transparency Diffused
Wavelength - Peak 565nm Green 635nm Red
Lens Color White
Forward Current-Max 0.03A
Forward Voltage-Max 2.6V
Overall Height 4.44mm
T-code T-1
Dimensions
Height (Max) 5.70mm
Compliance
RoHS Status Non-RoHS Compliant
