C5SMF-RJS-CT0W0BB2
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
CREE C5SMF-RJS-CT0W0BB2 LED, Screen Master, Red, Through Hole, T-1 3/4 (5mm), 20 mA, 2.1 V, 621 nm
PDF
/
Inventory: 3979
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Weight 4.535924g
Technical
Packaging Tape & Box (TB)
Series Screen Master?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 95°C
Min Operating Temperature -40°C
Color Red
Packing Method AMMO PACK
Number of Functions 1
Depth 3.7mm
Base Part Number C5SMF
Number of Elements 1
Configuration Standard
Power Dissipation 130mW
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 100 °
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Oval with Domed Top
Lens Size 5.10mmx3.70mm
Luminous Intensity 2.2 cd
Millicandela Rating 2640mcd
Lens Transparency Clear
Reverse Voltage 5V
Wavelength 621 nm
Dimensions
Height 10.95mm
Length 5.1mm
Width 12.7mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
