C566C-RFS-CV0W0BB2
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Red Oval LED
PDF
/
Inventory: 9123
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Technical
Packaging Tape & Box (TB)
Series Screen Master?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 95°C
Min Operating Temperature -40°C
Color Red
Packing Method AMMO PACK
Number of Functions 1
Depth 4.6mm
Base Part Number C566C
Number of Elements 1
Configuration Standard
Power Dissipation 130mW
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 70°, 35°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 50mA
Current - Test 20mA
Lens Style Oval with Domed Top
Lens Size 5.20mmx4.60mm
Luminous Intensity 3.155 cd
Millicandela Rating 3155mcd
Lens Transparency Diffused
Reverse Voltage 5V
Wavelength - Dominant 621nm
Dimensions
Height 11.9mm
Length 5.2mm
Compliance
RoHS Status RoHS Compliant
