C503D-WAN-CCBDB232
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color White 2-Pin T-1 3/4 Ammo
PDF
/
Inventory: 1321
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Radial
Number of Pins 2
Mounting Type Through Hole
Mount Through Hole
Technical
Packaging Tape & Box (TB)
Series C503D-WAN
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 95°C
Min Operating Temperature -40°C
Color White, Cool
Packing Method AMMO PACK
Number of Functions 1
Depth 5.9mm
Base Part Number C503D
Number of Elements 1
Configuration Standard
Power Dissipation 120mW
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 15°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Luminous Intensity 30 cd
Millicandela Rating 37150mcd
Illumination Color White
Lens Transparency Clear
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 9000K
Dimensions
Height 8.6mm
Length 5.9mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
