C503D-WAN-CBBDB152

Cree Inc.
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description LED COOL WHITE CLEAR 5MM RND T/H
PDF
/
Inventory: 2888
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height 8.6mm

Technical

T-code T-1 3/4
Wavelength - Dominant 9000K
Forward Current-Max 0.03A
Lens Color Colorless
Lens Transparency Clear
Illumination Color White
Millicandela Rating 33125mcd
Luminous Intensity 33.125 cd
Lens Size 5.00mm Dia
Lens Style Round with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 15°
Voltage - Forward (Vf) (Typ) 3.2V
Configuration Standard
Base Part Number C503D
Terminal Pitch 2.54mm
Number of Functions 1
Packing Method AMMO PACK
HTS Code 8541.40.20.00
Color White, Cool
Min Operating Temperature -40°C
Max Operating Temperature 95°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series C503D-WAN
Packaging Tape & Box (TB)

Physical

Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
