C503C-WAN-CBBDB152
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole White Round LED
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
≥10 USD $0.23584
≥100 USD $0.217976
≥500 USD $0.194955
Inventory: 1221
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Technical
Packaging Tape & Box (TB)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish NOT SPECIFIED
Max Operating Temperature 95°C
Min Operating Temperature -40°C
Color White, Cool
Packing Method AMMO PACK
Number of Functions 1
Depth 5.8mm
Base Part Number C503C
Number of Elements 1
Configuration Standard
Power Dissipation 120mW
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 15°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 30mA
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Luminous Intensity 35 cd
Millicandela Rating 33125mcd
Illumination Color White
Lens Transparency Clear
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 9000K
Dimensions
Diameter 5mm
Height 10.3mm
Length 5.8mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
