C503C-WAN-CBBDA231
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color White 2-Pin T-1 3/4 Bulk
PDF
/
Inventory: 9247
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Technical
Packaging Bulk
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 95°C
Min Operating Temperature -40°C
Color White, Cool
Subcategory Visible LEDs
Depth 5.8mm
Base Part Number C503C
Number of Elements 1
Configuration Standard
Power Dissipation 120mW
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 15°
Forward Current 30mA
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Luminous Intensity 29.825 cd
Millicandela Rating 29825mcd
Lens Transparency Clear
Lens Color Colorless
Reverse Voltage 5V
Forward Voltage-Max 4V
Wavelength - Dominant 9000K
Dimensions
Diameter 5mm
Height 8.8mm
Length 5.8mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
