C503B-WAN-CCACB151
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
CREE C503B-WAN-CCACB151 LED, HI BRIGHT, 5MM
PDF
/
Inventory: 4265
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Supplier Device Package 5mm Round
Technical
Packaging Bulk
Series C503B-WAN
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 95°C
Min Operating Temperature -40°C
Color White, Cool
Depth 5.8mm
Base Part Number C503B
Number of Elements 1
Configuration Standard
Power Dissipation 100mW
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 15°
Forward Current 25mA
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Forward Voltage 3.2V
Luminous Intensity 32.9 cd
Millicandela Rating 28200mcd
Lens Transparency Clear
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 9000K
Dimensions
Height 8.8mm
Length 5.8mm
Height (Max) 8.80mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
