C503B-RCN-CW0X0AA2
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Red Round LED
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1584
≥1 USD $0.1584
≥10 USD $0.15048
≥100 USD $0.139216
≥500 USD $0.124555
Inventory: 1105
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 5.8mm
Height 8.8mm
Technical
Wavelength - Dominant 624nm
Reverse Voltage 5V
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 4430mcd
Luminous Intensity 5.1 cd
Lens Size 5.00mm Dia
Lens Style Round with Domed Top
Current - Test 20mA
Forward Current 50mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 30°
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 130mW
Configuration Standard
Number of Elements 1
Base Part Number C503B
Depth 5.8mm
Number of Functions 1
Packing Method AMMO PACK
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Box (TB)
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
