C503B-RCN-CW0X0AA1
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Red 2-Pin T-1 3/4 Bulk
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1584
≥1 USD $0.1584
≥10 USD $0.15048
≥100 USD $0.139216
≥500 USD $0.124555
≥1000 USD $0.115658
Inventory: 493
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Technical
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Red
Number of Functions 1
Depth 5.8mm
Base Part Number C503B
Number of Elements 1
Configuration Standard
Power Dissipation 130mW
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 30°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 50mA
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Luminous Intensity 5.1 cd
Millicandela Rating 4430mcd
Lens Transparency Clear
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 624nm
Dimensions
Height 8.8mm
Length 5.8mm
Compliance
RoHS Status RoHS Compliant
