C503B-GCS-CY0A0892
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR 5MM T/H
PDF
/
Inventory: 2989
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Technical
Packaging Tape & Box (TB)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Color Green
HTS Code 8541.40.20.00
Packing Method AMMO PACK
Number of Functions 1
Terminal Pitch 2.54mm
Operating Temperature (Max) 95°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 30°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Luminous Intensity 11330.0 mcd
Millicandela Rating 11330mcd
Lens Transparency Clear
Lens Color Colorless
Forward Current-Max 0.03A
Overall Height 8.8mm
Wavelength - Dominant 527nm
T-code T-1 3/4
Dimensions
Height (Max) 12.70mm
