C503B-GAS-CC0D0892
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Green Round LED
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.226019
≥1 USD $0.226019
≥10 USD $0.213223
≥100 USD $0.201152
≥500 USD $0.189767
≥1000 USD $0.179025
Inventory: 1565
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Technical
Packaging Tape & Box (TB)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 95°C
Min Operating Temperature -40°C
Color Green
HTS Code 8541.40.20.00
Packing Method AMMO PACK
Number of Functions 1
Terminal Pitch 2.54mm
Base Part Number C503B
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 15°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Luminous Intensity 34.8 cd
Millicandela Rating 34800mcd
Lens Transparency Clear
Lens Color Colorless
Forward Current-Max 0.03A
Wavelength - Dominant 530nm
T-code T-1 3/4
Dimensions
Height 13.3mm
Compliance
RoHS Status RoHS Compliant
