C503B-GAN-CB0C0891
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Green Round LED
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.194182
≥1 USD $0.194182
≥10 USD $0.183193
≥100 USD $0.172826
≥500 USD $0.163041
≥1000 USD $0.153811
Inventory: 1286
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Technical
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 95°C
Min Operating Temperature -40°C
Color Green
HTS Code 8541.40.20.00
Number of Functions 1
Terminal Pitch 2.54mm
Base Part Number C503B
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 15°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Luminous Intensity 24.85 cd
Millicandela Rating 24850mcd
Lens Transparency Clear
Lens Color Colorless
Forward Current-Max 0.03A
Wavelength - Dominant 530nm
T-code T-1 3/4
Dimensions
Height 8.8mm
Compliance
RoHS Status RoHS Compliant
