C4SMK-BJS-CR14Q3S2
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
Screen Master? Oval with Domed Top C4SMK SINGLE COLOR LED LED Indication Discrete 4V 20mA 115 ° 742mcd
PDF
/
Inventory: 7680
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Technical
Packaging Tape & Box (TB)
Series Screen Master?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Max Operating Temperature 95°C
Min Operating Temperature -40°C
Color Blue
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method AMMO PACK
Number of Functions 1
Terminal Pitch 2.54mm
Base Part Number C4SMK
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 115 °
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Oval with Domed Top
Lens Size 3.90mmx3.00mm
Luminous Intensity 742 mcd
Lens Transparency Clear
Forward Current-Max 0.035A
Forward Voltage-Max 4V
Wavelength - Dominant 470nm
Reverse Voltage-Max 5V
Dimensions
Height 10.5mm
Compliance
RoHS Status RoHS Compliant
